EFIS Control Panel
Glareshield - EFIS Control Panel 700/800/900
Captain or First Officer
Mode Selector

Outer

APP –

  • Displays localizer and glideslope information in heading–up format.


VOR –

  • Displays VOR navigation information in heading–up format.
  • Displays reference VOR receiver, VOR frequency or identification,
    course, DME and TO/FROM information.
  • Weather radar and TCAS are not displayed in center VOR mode.

MAP –

Option - Track-up display

  • Displays FMC generated route and MAP information, airplane position,
    heading and track, in a track–up format.
  • Displays waypoints, including the active waypoint, within the selected
    range.
  • Displays VNAV path deviation.
