| EFIS Control Panel |
| Glareshield - EFIS Control Panel 700/800/900 |
Captain or First Officer
MAP Switches
Momentary action
The MAP switches:
POS (Position) –
Displays IRS positions, GPS positions and VOR bearing vectors extended
from the nose of the airplane symbol to the stations.
Momentary action
The MAP switches:
- Add background data/symbols to MAP and center MAP modes.
- The displays can be selected simultaneously.
- A second push removes the information.
POS (Position) –
Displays IRS positions, GPS positions and VOR bearing vectors extended
from the nose of the airplane symbol to the stations.
Generated Data and Symbols when selected: (Typical)
Valid VOR/ADF
signal shows
Radial/Bearing
as selected.
signal shows
Radial/Bearing
as selected.
ADIRU position relative
to FMC position.
to FMC position.
GPS position relative to
FMC position.
FMC position.
