EFIS Control Panel
Glareshield - EFIS Control Panel 700/800/900
Captain or First Officer
Generated Data and Symbol when selected: (Typical)
MAP Switches

Momentary action

The MAP switches:

  • Add background data/symbols to MAP and center MAP modes.
  • The displays can be selected simultaneously.
  • A second push removes the information.

STA (Station) –

  • Displays all FMC data base navigation aids if on map scales 5, 10, 20
    or 40 nm.
  • Displays FMC data base high altitude navigation aids on map scales
    80, 160, 320 or 640 nm.
