| EFIS Control Panel |
| Glareshield - EFIS Control Panel 700/800/900 |
Captain or First Officer
Minimums (MINS) Reference Selector
Outer (Two positions)
RADIO – selects radio altitude as the minimums reference.
BARO – selects barometric altitude as the minimums reference.
Middle (Slew - Hold and Release)
ROTATE –
adjusts the radio or barometric minimums altitude.
Reset Inner (RST) Switch (Momentary action)
PUSH –
Outer (Two positions)
RADIO – selects radio altitude as the minimums reference.
BARO – selects barometric altitude as the minimums reference.
Middle (Slew - Hold and Release)
ROTATE –
adjusts the radio or barometric minimums altitude.
Reset Inner (RST) Switch (Momentary action)
PUSH –
- Resets the alert minimums annunciation.
- Blanks minimums display if alert is not active.
