| Display Selector |
| AC and DC Metering Panel |
Cabin and Utilities (CAB/UTIL) Switch
OFF – removes electrical power from galley and cabin equipment
systems including:
ON – supplies electrical power to galley and cabin equipment
systems.
OFF – removes electrical power from galley and cabin equipment
systems including:
- All 115V AC galley busses.
- Cabin recirculation fan (737-700).
- Left & right cabin recirculation fans (737-800/900).
- Forward and aft door area heaters.
- Drain mast heaters.
- Lavatory water heaters.
- Logo lights.
- Potable water compressor.
- 115V AC shaver outlets when installed.
ON – supplies electrical power to galley and cabin equipment
systems.
