| Display Selector |
| AC and DC Metering Panel |
Battery Switch
OFF –
ON (guarded position) –
OFF –
- Removes power from the battery bus and switched hot
battery bus when operating with normal power sources
available.
- Removes power from the battery bus, switched hot battery
bus, DC standby bus, static inverter, and AC standby bus
when the battery is the only power source.
ON (guarded position) –
- Provides power to the switched hot battery bus.
- Energizes relays to provide automatic switching of the
standby electrical system to battery power with the loss of
normal power.
