| Overheat / Fire Protection Panel |
Overheat Detector (OVHT DET) Switch
Selects the active overheat / fire detection loop(s).
NORMAL (Center) – Detection loop A and loop B are active.
When A is selected – Detection loop A is the active loop.
When B is selected – Detection loop B is the active loop.
Selects the active overheat / fire detection loop(s).
NORMAL (Center) – Detection loop A and loop B are active.
When A is selected – Detection loop A is the active loop.
When B is selected – Detection loop B is the active loop.
The FAULT light illuminates if a single loop is
inoperative for the selected switch position( A or B).
If both detection loops are inoperative, the FAULT light
will be illuminated in the NORMAL (center) position.
inoperative for the selected switch position( A or B).
If both detection loops are inoperative, the FAULT light
will be illuminated in the NORMAL (center) position.
